Additional information
| Größe | L, XL |
|---|---|
| Rahmen | eONE-SIXTY LITE III, Material: Aluminium, 150mm suspension travel, 27.5×2.8" max. wheelsize, 148x12mm axle standard, intube |
| Gabel | Rock Shox ZEB Ultimate, Air, 160mm suspension travel, Tapered, 51mm fork offset, 29×2.8" max wheelsize |
| Federbein | Rock Shox Super Deluxe Select+, platform |
| Motor | Shimano EP8, 85Nm |
| Batterie | Simplo Internal Battery, 750Wh |
| Display | Shimano SC-EM800 |
| Switch | Shimano SW-EM800-L |
| Schaltwerk | Shimano XT RDM8130 Shadow+ 11 |
| Schalthebelklemme | Jagwire Flex-SL:CP |
| Schalthebel | Shimano SL -MT500-IL/Shimano XT M8130 |
| Kurbel | Shimano FCEM600, 165 mm |
| Kassette | Shimano LG600, 11-50 teeth, 11 speed |
| Kettenblatt | Shimano CRE80-B, 34 teeth |
| Bremsen | Shimano XT, 4 piston |
| Bremsscheiben | Shimano RT-MT900/Shimano RT-EM910, 203 mm |
| Lenker | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Griffe | MERIDA EXPERT EC |
| Vorbau | MERIDA EXPERT eTRII, Material: Aluminium, 35mm diameter, 0° stem angle, GoPro & Supernova mount, 40 mm |
| Steuersatz | MERIDA 8152 |
| Sattel | MERIDA EXPERT CC, V-mount, incl. MERIDA minitool |
| Sattelstütze | MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS 100mm travel seatpost – S 125mm travel seatpost – M 150mm travel seatpost – L/XL 170mm travel seatpost |
| Sattelklemme | MERIDA EXPERT |
| Scheinwerfer | Lezyne E-Bike Power E115, StVZO, Reverse MERIDA Custom Mount |
| Rücklicht | Lezyne LED Femto USB, StVZO |
| Schutzbleche | C093-02F + C093-02R |
| Naben | Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Achse | MERIDA EXPERT TR, including removeable lever, 6/4mm allen key |
| Felgen | MERIDA EXPERT TR, 29mm inner width, Material: Aluminium, Tubeless ready |
| Reifen | Maxxis Assegai/Maxxis DHR II, 29×2.5 ", fold, TR EXO+ 3C MaxxGrip, 27.5×2.6 ", fold, 3C EXO+ TR |
| Zulässiges Gesamtgewicht | 140 kg |
